ZIMMER Polymerization Line to produce chips - 1995 year
240,000 kg/d with IV range of 0.55 ~ 0.66
260,000 kg/d with IV range of 0.55 ~ 0.64
New DCS system controls
2 X AQUAFIL Technology reactors installed in 2014 to produce bright polymer

BARMAG Filament spinning lines - 1991/92/95 years
Type 9E4/24D Extruder - 90mm
Drying/Crystallizing
Quenching
Each line with 12 x Winders type CW6R and CW6R-920/4 - 4 ends each

BARMAG Filament spinning lines - 1997 year
Type 12E811-48/6V Extruders
Drying/Crystallizing
Quenching
Each line with 14 x winders type CW6R-55-1605Z - 8 ends each

OERLIKON BARMAG POY Extrusion Line for Polyester -- 2011 year – 80 thread lines
* (1) Horizontal Extruder (e-save) type 9E10, 90mm ø
* (1) Continuous Polymer Filter (60 – 300 kg/hour)
* (2) Spinning Heads type SP87D(DIO), 2 pos per module
* (10) PC Spin packs/position
* (8) Spinning Pump drive (1 extra)
* (10) Spinning Pumps type GH30XK Planetary
* (4) Eco Quench Radial Inflow system (suitable for micro denier)
* (1) Spin Finish Supply system inc. 10 x Spin Finish pumps type GFD1XA-50
* (1) Heat transfer installation inc Vaporization vessel of heating cap. 59.28kw
* (1) Control panels, inverters, etc.
* (8) Take up Winders type WINGS POY 40T-1500 with 10 positions each
* (1)  Spare winder

BARMAG Texturizing machine type eAFK-PES - 2017 year
2 heaters
Autodoffing
288 positions
Denier range: 22~330
Unitens tensioning
Air Entangling
Individual motor friction disc drives

TMT Texturizing machines type ATF-21 - 2010 year
2 heaters
Autodoffing
240 positions
Denier range: 22 ~ 167
TCS tensioning
Air Entangling
Individual motor friction disc drives

BARMAG Texturizing machines type AFK MULTI ATT (Diphyl) - 2001 year
2 heaters
Autodoffing
216 positions
Unitens tensioning
Air Entangling
Individual motor friction disc drives

BARMAG Texturizing machines type AFK
2 heaters
Autodoffing
216 positions each
Unitens tensioning
Air Entangling
Individual motor friction disc drives
* 22 x type AFK-V - 1996/1997/1998 year
Denier range: 50 ~ 300
* 6 X type AFK-M - 1997 year
Denier range: 75 ~ 300

BARMAG Texturizing machines type FK6-M900 - 1994 year
2 heaters

BARMAG Texturizing machines type FK6-M80 - 1980/92 year
2 heaters
2, 3 and 4 ply capability

Yarn Lab
details on request
